The Earthquake EQ line of Maximum Musical Output drivers are specifically designed to provide smooth, low-distortion mid-range/mid-bass output for the highest quality sound reinforcement applications.

Because of their relatively high resonance and very low Qts values, the EQ line can be mounted in small enclosures while maintaining a smooth, peak-free response.

Box dimensions

10 x 18 x 18 cm

Weight

2.375 kg

Specifikationer

Woofer Size

6.5″ Midbass

MAX Power

60W

Frequency Response

377Hz – 5kHz

Nominal Impedance

8 ohm

Sensitivity

93dB to 110dB

Fs

377 Hz

Produkt Dimensioner

Diameter

169.5 mm

Cut out hole

142 mm

Mounting Depth

66.9 mm

Parameters

Xmax

0.2mm

Qts

1.214

Qes

1.72

Qms

4.122
