XJ-700-DSP – LFE Mono Block Amplifier with Built-in DSP Module

Earthquake’s XJ-700-DSP is the newest addition to the XJ Series of home and professional audio amplification. Like the XJ-700R, it addresses the need to correctly adjust a room to precision audiophile status, but now with the added benefits of controlling the DSP from your finger tips via a mobile app. You can take full advantage of what this subwoofer amplifier has to offer by making on-the-fly adjustments for the utmost in sound quality and user control with features like auto room correction and up to 60dB/Oct filters.

Box dimensions

15 × 38 × 56 cm

Weight

9.4 kg

Specifikationer

Output Power

1 x 400 WRMS @ 8-Ohm
1 x 700 WRMS @ 4-Ohm

THD

< 0.02% (1W/4-Ohm)

Frequency Response

13Hz -160Hz

Damping Factor

> 500

Load Impedance

4 Ohms or greater

Low Pass Filter

40Hz–160Hz (Low Pass Variable Filter)

Others

Output Connections

5-Way binding posts
RCA (DSP OUT)

S/N

> 108dB (unbalanced)
> 112dB (balanced)

Slew Rate

50 V/ms

• 0–180° Phase Adjustment
• App Controlled DSP (iWoofer™ Pro recommended)
• Built-in Boundary Equalizer
• Class J Circuitry
• DSP ON/OFF Switch
• Movie/Music Mode Preset Button
• ON/AUTO/+12V Signal Sensing
• Rack Mountable (1U space)
